| Model No. |
VPP-3020 CNC |
VPP-4030 CNC |
| X Y Work Stage |
| Size of Top Plate |
430 x 330 mm |
610 x 460 mm |
| Traverse: X & Y axis |
300 x 200 mm |
400 x 300 mm |
| Load Capacity |
25 Kg |
30 kg |
| Z axis Travel |
200 mm |
300 mm |
| Base and column |
Made of 0-0 grade Granite |
| Video System |
Imaging Device 1/2” Sony CCD camera |
| Lens |
High Resolution Tele-centric Zoom Lens |
| Magnification Range |
10 x - 250 x |
| Illumination System |
Profile
|
LED Array placed below |
| Surface |
4 quad PC controlled zone Light |
| Measurement System |
| Linear Measurement X Y Z Axis |
Linear Encoders 1 u LC |
| Measurement Software |
3D Geometric Measurement Software with CNC programming Software with CNC programming |
| SPC |
Advanced SPC Software in built |
| Measuring Accuracy |
(3 + L/100) microns |
| Computer |
Latest Computer with 17" LCD Monitor Windows XP OS |
| Optional Accessories |
Renishaw Touch Probe |
| Physical Specifications |
| Net Weight |
280 Kgs |
410 Kgs |
| Overall Dimensions |
1200 x 720 x 1600 mm |
1250 x 900 x 1571 mm |
